Dual Cellular Router for Mobile Outdoor DeploymentsDual Cellular Router for Mobile Outdoor Deployments

Peplink

MAX HD2 Dome

The HD2 Dome provides dual-cellular Bandwidth Bonding in an IP67 enclosure that has a minimal profile on the rooftop while providing maximum signal. With redundant SIM, the HD2 Dome supports two cellular radios and four SIM cards. Combine the HD2 Dome with the SIM Injector, and the number of cards increases to twelve.

Minimum Cable Loss, Best Cellular Signal Quality

Minimum Cable Loss, Best Cellular Signal Quality

Simple Installation Running a Single Ethernet Cable

Simple Installation Running a Single Ethernet Cable

SIM Injector – More SIM, More Range

Certified Toughness

In addition to rugged metal enclosure, the MAX HD2 is certified on:(EN 61373:1999 IEC 61373:1999)(ITU-T K.20 (+/- 1.5 kV))(EN 50155)(EN 61000)

Speed & Reliability. Brought by SpeedFusion™

SpeedFusion allows users to combine any number of connections together to form a point-to-point link to achieve what others cannot:

Minimum Cable Loss, Best Cellular Signal Quality

Most outdoor deployments require a centrally placed router attached to strategically placed antennas. With the HD2 Dome, the antennas are placed in the same integrated enclosure as the cellular radios. This arrangement minimizes cable loss, giving you the best signal possible.

Simple Installation Running a Single Ethernet Cable

The HD2 Dome has a M35 screw mount, and only requires a single Ethernet cable to install. For wall or pole mounted deployments, the HD2 Dome comes with an Ethernet splitter and a mounting rack that provides a multitude of installation options.

8 Additional SIM With the SIM Injector

With the addition of the SIM Injector, the HD2 Dome can support up to 12 SIM at your fingertips. Simply connect an Ethernet cable between the SIM Injector and the HD2 Dome. The SIM Injector is capable of PoE output, so you don’t need to add another PoE switch to your deployment.

FirstNet Ready

FirstNet (band 14) provides first responders with a specialized LTE network with more priority and network capacity. The HD2 Dome supports band 14, providing additional coverage as the situation demands.

Fleet Tracking and Management

With built-in GPS fleet tracking and InControl 2 cloud-based management, you can keep tabs on location and manage your mobile network from any Internet-connected device. InControl 2 is our cloud based device management, monitoring, and reporting tool designed specifically for Peplink and Pepwave devices.

Multiple Mounting Options

The HD2 Dome offers significant deployment flexibility due to its modular construction. By itself, it has an M35 thread, making it easy to mount on top of any pole or on the rooftop of any vehicle.The HD2 Dome comes with an Ethernet splitter that enables an additional GE LAN output. With the splitter installed, the HD2 Dome can then be used with the included mounting bracket to fix onto any wall, or to securely tie onto any pole.The HD2 Dome, Ethernet splitter, and the mounting bracket are all included, so you can deploy this device just about anywhere.

Technical specifications
SKUs
